BK Precision 9202 Multi-Range Programmable DC Power Supply 0-60 Volts, 0-15 Amps. 360 W

BK Precision 9202 Multi-Range Programmable DC Power Supply 0-60 Volts, 0-15 Amps. 360 W
BK Precision 9202 Multi-Range Programmable DC Power Supply 0-60 Volts, 0-15 Amps. 360 W

Alternative Views:
Discontinued


Product Code: 9202

Description Extended Information

Features
Any 9200 series model can replace several supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, these multi-range power supplies automatically recalculate voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.

For benchtop applications, these power supplies provide a numerical keypad for direct data entry along with convenient cursors and analog style knobs to quickly make incremental voltage or current changes. System integrators benefit from the standard USB (USBTMC-compliant), RS-232, and GPIB interfaces supporting SCPI commands.

  • Multi-ranging operation
  • High programming and readback resolution of 1 mV/0.1 mA
  • Output timer function
  • List mode programming
  • Store and recall up to 72 instrument settings
  • Standard USB (USBTMC-compliant), RS-232, and GPIB interfaces supporting SCPI commands for remote control
  • Remote sense
  • Overvoltage protection (OVP), overpower protection (OPP), overtemperature protection (OTP), and key-lock function
  • NI-certified LabVIEW driver and softpanel for remote control, test sequence generation, and datalogging available
  • Compact 19" half-rack form factor allows for side-by-side rack mounting of two units
