| DC Volts |
Manual ranging |
| Ranges |
200 mV, 2V, 20V, 200V, 1500V |
| Resolution |
100 uV, 1 mV, 10 mV, 100 mV, 1V |
| Accuracy |
+-(0.5% rdg + 1 dgt) |
| Overload
protection |
1500V peak |
| Input
Impedance |
10 MΩ |
| AC
Volts |
Manual ranging |
| |
avg. responding, rms reading |
| Ranges |
200mV, 2V, 20V, 200V, 1000V |
| Resolution |
100uV, 1 mV, 10 mV, 100 mV, 1V |
| Accuracy |
+-(1.25% rdg + 4 dgt) |
| Frequency
Response |
40 kHz - 500Hz |
| Overload
Protection |
1500V peak |
| Input
Impedance |
10 MOHm |
| Current |
Manual ranging |
| |
AC avg. responding, rms reading |
| Ranges |
200uA, 2 mA, 20 mA, 200 mA, 20A* |
| Resolution |
0.1uA, 1uA, 10 uA, 100 uA, 10 mA |
| Accuracy
(DC) |
+-(1.0% rdg + 1 dgt) |
| |
+-(2.0% rdg + 3 dgt) for 20A |
| Accuracy
(AC) |
+-(1.5% rdg + 3 dgt) |
| |
+-(2.5% rdg + 4 dgt) for 20A |
| Frequency
Response |
40Hz - 500Hz |
| Overload
Protection |
High energy 600V, 1A full for uA/mA, High energy 600V, 15A for
20A |
| Resistance |
Manual ranging |
| Ranges |
200Ω, 2 kOhm, 20kOhm, 200kOhm, 2MOhm, 20MOhm |
| Resolution |
0.1Ω, 1 Ohm, 10Ohm, 100Ohm, 1 kOhm, 10 kOhm |
| Accuracy |
+-(0.75% rdg + 1 dgt) |
| |
+-(1.5% rdg + 5 dgt) for 20MΩ |
| Overload
Protection |
600V peak |
| Diode
Check |
Tested at 1.5 mA, 3.3V max typical tested at 1 mA 3.2V max
typical |
| Continuity |
Beeper sounds below 100 Ω approx. |
| Display |
0.8'' LCD, 1999 count |
| Sampling
rate |
2.5/sec. |
| Operating
Temperature |
32 0 to 122 0 F (0 0 C to 50 0 C), < 80% RH |
| Power |
Single 9V battery |
| Battery
life |
250 hrs typ (alkaline) |
| Auto
power off |
Approx. 30 min. |
| Dimensions
(HxWxD) |
6.88x3.5x1.5'' (175x89x38 mm) |
|
|
|
